Sony XDCA-FX9

Rozširujúci modul pre kameru PXW-FX9 umožňujúci kamere posielať 16-bitový RAW signál, pripojiť bezdrôtový dvojkanálový slot-in prijímač či posielať video stream cez dvojicu 4G USB adaptérov alebo cez LAN kábel.

Více informací

69 936 Kč s DPH 57 798 Kč bez DPH
-+
Dostupnost
na dotaz

Ukázat všechno příslušenství

Popis produktu SPECIFIKACE

Popis produktu

Rozširujúci modul pre kameru PXW-FX9 umožňujúci kamere posielať 16-bitový RAW signál, pripojiť bezdrôtový dvojkanálový slot-in prijímač či posielať video stream cez dvojicu 4G USB adaptérov alebo cez LAN kábel.

Enhanced operability with advanced networking, wireless audio* and RAW output**

Connecting directly to the PXW-FX9 camera with no cables needed, the XDCA-FX9 extension unit provides convenient additional features to enhance shooting convenience and flexibility.

The XDCA-FX9 allows easy fitting of BP-GL and BP-FL series batteries, extending camera operating times during the most demanding shoots.

Attaching quickly and easily to the rear of the PXW-FX9 via a MultiPin connector, the XDCA-FX9 provides advanced networking capabilities for streaming or file transfer via Ethernet or dual link cellular connection. It also allows the easy addition of high quality wireless audio via a wireless receiver slot.* Additional output connectors including timecode and D-tap are also provided.

16-bit RAW signals can be output directly from the XDCA-FX9 using a third-party external recorder.**

Requires PXW-FX9 future firmware release for wireless audio and RAW output.


Seamless attachment, superb ergonomics
The XDCA-FX9 attaches directly to the PXW-FX9 via MultiPin connector, with no additional cabling required. Shooting time is extended by compatibility with Sony BP-GL and BP-FL series batteries. When using larger lenses, the extension unit balances any possible front heaviness while increasing stability when the camera is shoulder mounted.


Advanced network capabilities
The built-in networking capabilities of the PXW-FX9 enable streaming and file transfer via Wireless LAN. The XDCA-FX9 adds QoS Streaming with Dual Link connection via multiplexing of two cellular networks or Ethernet connection to improve image quality and stability.


Wireless audio support*
Ideal for field-based news production, the extension unit adds a wireless audio receiver slot for compatibility with receivers such as DWX series and URX series.

* Requires PXW-FX9 future firmware release.

16-bit RAW recording with external recorder**
Adding the XDCA-FX9 extension unit to the PXW-FX9 allows recording of 16-bit RAW footage from the camera on a third-party RAW recorder (available separately). RAW data is output directly via the extension unit’s RAW interface.

** Requires PXW-FX9 future firmware release. Limited to 10-bit recording during 120fps high frame rate shooting within Super35 image circle.



SPECIFIKACE



Camera Interface Not Specified by Manufacturer
Supported Video Formats     Not Specified by Manufacturer
DC Input Not Specified by Manufacturer
Battery Connector 1 x V-Mount
Power Input 1 x 4-Pin XLR
DC Output 1 x 4-Pin Hirose
1 x D-Tap
Other Connectors 1 x Timecode Output
1 x Reference Output



Parametry

Parametry

Výrobce: SONY
Kategorie: Různé
