Datavideo HS-2850-8

Datavideo HS-2850-8 je prenosná SD/HD 8 kanálová video réžia so 17,3" LCD displejom, disponujúca efektami, zabudovaným intercomom a tally systémom.

Více informací

251 344 Kč s DPH 207 722 Kč bez DPH
-+
Dostupnost
7-14 dní
Kód zboží:
2200-2061
Přidat do porovnání
Popis produktu

Popis produktu

Datavideo HS-2850-8 je prenosná SD/HD 8 kanálová video réžia so 17,3" LCD displejom, disponujúca efektami, zabudovaným intercomom a tally systémom.

HD/SD 8/12-CHANNEL PORTABLE VIDEO STUDIO

Watch the Video

A COMPLETE AND PROFESSIONAL STUDIO MADE FOR BIG EVENTS.

This professional studio includes a built-in switcher, intercom, tally, audio delay and monitor.



IDEAL FOR LARGE-SIZED LIVE VIDEO PRODUCTIONS.

Supports up to 12 HD or SD inputs in a variety of configurations, 3 SDI and 1 HDMI freely assignable outputs.



CREATE IMPRESSIVE VIDEO EFFECTS TO ENHANCE YOUR PRODUCTION.

2 x PIP and 2 x DSK assignable for luma key or alpha key.

17.3" LED BACKLIT MONITOR

Built-in Monitor Display. 17.3” HD TFT LED backlit monior with resolution 1920x1080 pix.

BUILD IN INTERCOME SYSTEM

Built in 8 Channel Intercom/Talkback system (4 x belt packs supplied)

BUILT-IN TITLE OVERLAY

Add custom graphics to help tell your story with the built-in title overlay system.

PERFECT LIP SYNC

The SE-2850's included audio-delay feature ensures that you'll be able to keep your audio and video perfectly in sync with one another. This means zero lip sync issues for your professional production.

ASSIGNABLE CROSSPOINTS

The SE-2850's inputs can be reassigned, giving you more flexibility while organizing the multi-view interface.

SUPPORTS 12 HD OR SD INPUTS IN A VARIETY OF CONFIGURATIONS

HD Mode: (1) 12 HD-SDI , (2) 9 HD-SDI + 3 HDMI
SD Mode: (1) 12 SD-SDI , (2) 9 SDI + 3 HDMI

REAL-TIME CLOCK FEATURING HH:MM:SS ON THE MULTI-SCREEN

Count down counter MM:SS

OBSAH BALENÍ

  • 1 x HS-2850 Unit
  • 1 x AD Switch DC 12V with AC Cord
  • 1 x CB-41 / XLR to XLR Cable
  • 4 x CB-3 / XLR cable
  • 1 x USB Light
  • 1 x Goose neck MIC
  • 4 x Headphone Microphone
  • 4 x ITC-100SL
  • 1 x Tally light
  • 4 x Velcro
  • 1 x Thank You Card

SPECIFIKACE

HS-2850 HD/SD 8/12-Channel Portable Video Studio
Video Standard

HD & SD

Video Format

3G/HD/SD Input:
1080i 50/59.94/60Hz
1080p 25/30/59.94/60Hz

HD Output:
1080p 25/29/30Hz
1080i 50/59.94/60Hz
SD: 576i 50Hz, 480i 59.94Hz

Input Routable / Crosspoint

All 12, repeatable

Video Input

Standard: 8x SDI, 2x HDMI
Max: 12x SDI, 3x HDMI

Computer Graphic Interface

Max 3 via HDMI

Down-converted Output

3x SDI

Video Output

3x SDI assignable: PGM, PVW, AUX & Clean Out
1x HDMI assignable: PGM & multi-view

Audio Input

4x Balanced XLR

Audio Output

2x Balanced XLR

Embedded Audio Support

Input up to 16 channels,
Output 4 channels

Audio Delay Calibration

Up to 8 frames

A+V Switching

Yes

USK

N/A

DSK

2x DSK support Lumakey & Linear key
(Key / Fill)

Picture in Picture

2

Logo Insertion

2 (or 1 logo + 1 clock)

Built-in Audio Mixer

N/A

Built-in Monitor Display

17.3” HD TFT LED backlit, 1920x1080 pix

Built-in Intercom & Tally

8 channels (4 belt-packs incl.)

Special Features

Built in TC-200 CG interface

Dimension (LxWxH)

455 x 355 x 134 mm

Weight

18.7 Lbs (8.5 kg), Reinforce Plastic Case

Power

DC 12V, 6A

Operating Temp. Range

0~40 °C

Options

CB-22H/23H/46/47/60/61/62

What's in the Box

1 x HS-2850 Unit
1 x AD Switch DC 12V with AC Cord
1 x CB-41 / XLR to XLR Cable
4 x CB-3 / XLR cable
1 x USB Light
1 x Goose neck MIC
4 x Headphone Microphone
4 x ITC-100SL
1 x Tally light
4 x Velcro
1 x Thank You Card

Parametry

Parametry

Výrobce: Datavideo
Kategorie: Live mobilní střižny
